LS Electric MC-65A Metasol Contactor – 3-Pole, 65A, 24VAC Coil 50/60Hz, Screw-Terminal, DIN-Rail/Panel Mount (MC65A-30-00-B7-S-E)
The LS Electric MC-65A Metasol Contactor is a heavy-duty 3-pole switching device designed for industrial motor control, automation systems, and high-demand electrical panels. Featuring a 24VAC coil (50/60Hz), this contactor integrates smoothly into standard AC control circuits commonly used in factories, commercial facilities, and OEM equipment. With a 65A AC-3 rating, it provides dependable performance for larger motors, pumps, compressors, and other medium-to-heavy industrial loads. The MC-65A is part of LS Electric's proven Metasol series, engineered for durability, stable operation, and long electrical life. Screw-terminal wiring and dual mounting capability—DIN-rail or panel—make installation straightforward for electricians, control panel builders, and maintenance teams. Its robust construction and compact form factor support reliable performance even in demanding industrial environments. This product is intended solely for electrical switching and motor-control applications. It does not perform any cleaning, treatment, or pest-related functions of any kind.
Additional details
- Contact Material : Silver Alloy
Features & Specs
- Coil Voltage : 24 Volts (DC)
- Connector Type : Clamp, Screw
- Contact Current Rating : 50 Amps
- Contact Type : Normally Open
- Current Rating : 50 Amps
- Maximum Switching Voltage : 240 Volts (DC)
- Mounting Type : DIN Rail Mount
- Number of Terminals : 3
Item details
- ASIN : B0FJ34H552
- Brand Name : Polar Energy
- Global Trade Identification Number : 00810201381415
- Included Components : Unit
- Manufacturer : LS Electric
- Model : MC-65a AC24V 50/60Hz
- Part Number : MC50A-30-00-B7-S-E
User guide
- Specification Met : cUL
